Топ дуо: Новата серия на Canadian Solar и монтажната система iFIX

The voestalpine Automotive Components Schwäbisch Gmünd GmbH & Co. KG has been a symbol of quality and service in the field of forming technology for decades. As a supplier to the automotive industry, they have achieved a high level of technical innovation and are now directing their investments towards the solar industry.

The patented iFIX system solution is an easy, fast, and reliable solution that can be customized to customer needs and integrated seamlessly.


The complete package
Choosing the right solar panels from an endless array of options can be challenging enough, let alone selecting the right mounting system to achieve the best results.

But with us, it's a piece of cake. Canadian Solar CS 6.2 solar panels and iFIX structures are a perfect match, ensuring stable and secure mounting of solar panels while maximizing their performance thanks to optimal tilt.

We are an authorized Canadian Solar distributor, so you are guaranteed not only fast delivery and unbeatable prices, but also the assurance of full technical support. This even applies to iFIX structures.

What exactly is iFIX?
iFIX is an intelligent support structure for photovoltaic systems, consisting of a single component instead of many different ones.

It provides you with a stable and long-term solution for mounting photovoltaic panels, is designed for flat roofs, provides a 10° slope and offers two variants: east-west and south.

It also boasts corrosion protection with a zinc and magnesium coating and uses steel sheet. The main advantage is its simple and quick installation with a single click.



Why choose the iFIX mounting system?

• Simple and quick installation: Just one click and you're done! Installation is easy and intuitive – no unnecessary complications.

• Made in Europe: High-quality manufacturing ensures a long service life, which is crucial when the panels come with a warranty of up to 30 years.

• Excellent price: You can purchase our structures at a great price, and thanks to our European supplier, you don't have to wait months for delivery.

• Reliability and safety: The high-quality construction ensures long-term trouble-free functionality. Saving on construction does not pay off – costly repairs and the risk of material damage can arise if you use poor-quality systems.

• Warranty: 12 years

A huge advantage is the time-saving installation and simple procedure using only a few parts. The base has all the mounting points needed for screw connection of the module. Other necessary parts can be selected specifically depending on the photovoltaic module installed.

All frame photovoltaic modules can be easily mounted on the iFIX system support structures.

South variant

It is based on the iFIX EAST-WEST snap-in system for east-west orientation. As usual, the PV support plate from the iFIX EAST-WEST (east-west) system is snapped into the new S connector. The iFIX deflector is simply inserted. It closes off the north side and thus reduces the load.

Canadian Solar solar panels
Canadian Solar, a manufacturer of solar cells, panels, systems, and related accessories, is one of the world's leading companies. It has been operating on the market since 2001 and is one of the manufacturers with the longest tradition.

Canadian Solar panels provide high energy yield even in low light conditions. They are also characterized by good shade tolerance. Canadian Solar panels have received high ratings in quality tests conducted by the California Energy Commission PVUSA.

They ranked first in Newsweek's 2024 list of the world's most trusted companies in the energy and public services sector. In 2024, they received the Best Photovoltaic Brand in the US award from EUPD Research.

CS6.2-48TD-460 BF
Monocrystalline solar panel with 460Wp output and 23% efficiency.Lower temperature coefficient (Pmax): Pmax: -0.29°C, increases energy yield in hot climates. Lower LCOE and system costs.
Suitable for year-round use thanks to its resistance to high snow loads of up to 6000 Pa and wind loads of 4000 Pa. Tested against hailstones with a diameter of 35 mm in accordance with IEC 61215 standards.

Year-round availability, suitable for any of your projects.

Width: 113.40 cm
Height: 176.20 cm
Depth: 3.00 cm
Technology: TOPCon
Panel type: Glass-glass

CS6.2-54TM-510 BF
Solar panel with a power output of 510 Wp and an efficiency of 22.9%. Elegant glass-glass design available in monocrystalline version. This technology uses N-type TOPCon, and panels with this technology produce more energy compared to traditional PERC panels.
Excellent performance against LeTID and PID. Low power degradation, high energy yield.

New in our range!

Width: 113.40 cm
Height: 196.10 cm
Depth: 3.00 cm
Technology: TOPCon
Panel type: Glass-glass
